- 3500 Watt RMS / 7000 Watt Peak
- Dual 1 or 2 ohm voice coils
- Optional carbon cone/dustcap available
- Custom tooled basket
- Custom-tooled ultra-linear spider packs
- Extended shorting ring
- Eight-layer voice coil
- Custom tooled basket
- Cast aluminum cooling ring
- Ultra-linear spider pack
- Unique air exchanging system forces hot air out and cool air in
- Aluminum vent ring
- Ultra-linear Mega Roll V2 surround
Features:
The Nightshade 3,000-watt Neodymium sub is engineered to deliver incredibly powerful low end, with an extremely linear excursion and next-level thermal management. It features an eight-layer voice coil for excellent power handling and an extended shorting ring to minimize distortion and deliver a smooth, highly accurate sound at extreme SPL levels.
Thermal control is optimized with a cast aluminum cooling ring, outer fin array and aluminum vent ring to actively pull heat away from the entire voice coil gap. The subwoofer also incorporates a unique air exchange system for active cooling, enhancing reliability during extended use. With a Mega Roll V2 surround for linear cone movement and class-leading Xmax, the Nightshade is the premier high-performance Neodymium subwoofer in the category.
Specifications:
NS V.6 10
| RE (Ohms) | 1.8759 | 3.606 |
| FS (Hz) | 44.386 | 43.7789 |
| VAS (L) | 6.2193 | 6.4844 |
| Qes | 0.5400 | 0.3963 |
| Qms | 5.4793 | 4.2627 |
| Qts | 0.4916 | 0.3626 |
| Le (mH) | 1.6541 | 3.2481 |
| BL (NA) | 19.5266 | 30.9683 |
| Mms (Grams) | 393.5975 | 388.0577 |
| Cms (uM/N) | 32.6651 | 34.0577 |
| Sens (dB @ 1w/1m) | 81.7782 | 83.1238 |
| Xmax | 35mm | 35mm |
| T/S SPECS | NS V.6 10″ D1 | NS V.6 10″ D2 |
|---|
ENCLOSURE SPECIFICATIONS
| Sealed Enclosure | Not Recommended |
| Ported Enclosure | 1.5 cu.ft. net |
| Recommended Tuning | 32 Hz |
| Recommended Port Area |
22 sq.in. |
| Displacement | .23 cu. ft. |
| Depth | 12.24" |
| Outside Diameter | 11.81" |
| Cut-Out | 10.1" |
| Physical Dimensions | Download |
