The 800.5 EVO6 is an amplifier with an ultra compact and modern design that delivers 800W RMS of power in 5 channels.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects. | Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 800.5 EVO6 - 4Ω
Power @ 4Ω: 4 x 100W RMS
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W
Bridged Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A -
Frequency response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz -
Low Pass Filter (12dB/octave): 80Hz
-
High Pass Filter (12dB/octave): 80Hz
-
Supply voltage: 9V ~ 16V
-
Signal to noise ratio: 103.88dB
SUBWOOFER: 102dB -
Input Sensitivity (RCA): 0.2V ~ 2V
-
Music consumption: 39A
-
Consumption with resistive load: 78.7A
-
Overall efficiency: 80%
-
Damping factor (@100Hz nominal impedance): 200
-
Power cord: 10mm² (7 AWG)
-
Speaker/Subwoofer Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)
-
Recommended fuse* (musical use): 40A
-
Recommended battery (minimum): 60Ah
-
Width: 15.7 cm
-
Length: 11.7 cm
-
Height: 5.5 cm
-
Weight: 0.75 kg
