Beschrijving
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 800.1 EVO 5 - 2Ω
Power @ 2Ω: 800WRMS
Power @ 4Ω: 528WRMS
Power @ 8Ω: 348WRMS -
SD 800.1 EVO 5 - 4Ω
Power @ 2Ω: N/A
Power @ 4Ω: 800WRMS
Power @ 8Ω: 528WRMS -
Frequency Response: 10Hz ~ 20kHz
-
Subsonic Filter (HP 12dB/8º): 10Hz ~ 80Hz
-
Low Pass Filter (LP 12dB/8º): 50Hz ~ 20kHz
-
Operating Voltage: 8V ~ 16V
-
SNR:
2Ω: 96dB
4Ω: 97dB -
Input Sensitivity (RCA): 0.2V ~ 4V
-
Input Sensitivity (High Level input): 1.5V ~ 15V
-
Current Draw (Music):
2Ω: 40A
4Ω: 38A -
Current Draw With Resistive Load (1kHz @ 12.6V):
2Ω: 81A
4Ω: 77A -
Total Efficiency:
2Ω: 79%
4Ω: 78% -
Damping Factor (@100Hz Rated Impedance):
200
-
Power Cable: 10mm² (7AWG)
-
Audio Output Cable: 2 x 2mm² (12 AWG)
-
Recommended Fuse (Music): 40A
-
Recommended Battery (Music): 60Ah
-
Width: 4.4 in / 11,3 cm
-
Length: 5.8 in / 14,8 cm
-
Height: 2 in / 5,1 cm
-
Weight: 1.54 lb / 0,7 Kg
