Beschrijving
SD EVO 5 wordt alleen aangeraden voor PA/Car speakers, PA/Car bullets, PA drivers en PA woofers.
Klik hier voor de SD 5000.1 EVOX2 (hogere kwaliteit mosfets, grotere power supply section, tiffany rca, efficiënter en robuuster in alle aspecten vergleken met de EVO 5 componenten)
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 5000.1 EVO 5 - 1Ω
Power @ 1Ω: 1 X 5000 WRMS
Power @ 2Ω: 1 X 3300 WRMS
Power @ 4Ω: 1 X 2178 WRMS -
SD 5000.1 EVO 5 - 2Ω
Power @ 1Ω: N/A
Power @ 2Ω: 1 X 5000 WRMS
Power @ 4Ω: 1 X 3300 WRMS -
Response frequency (-3dB): 5Hz ~ 6kHz
-
Low pass filter (12dB/octave): 50Hz ~ 6kHz
-
Subsonic filter (12dB/octave) 5Hz ~ 80Hz
-
Supply Voltage: 8V ~ 16V
-
Signal-to-noise ratio: 90dB
-
Input sensitivity (RCA): 0.2V ~ 2V
-
Input sensitivity (high input): 1.2V ~ 12V
-
music consumption: 230A
-
Maximum consumption: 461A
-
Total efficiency: 86%
-
Damping factor (@100Hz nominal impedance): >2000
-
Power cable: 50mm² (0 AWG)
-
Audio output cable:
1Ω: 2 x 10mm² (7 AWG)
2Ω: 2 x 6mm² (9 AWG) -
Recommended fuse (musical): 250A
-
Recommended battery (minimum for music use): 250Ah
-
Width: 18 cm
-
Length: 25 cm
-
Height: 6.32 cm
-
Weight: 2.75 kg
