Beschrijving
Klik hier voor de SD 400.4 EVOX2 (hogere kwaliteit mosfets, grotere power supply section, tiffany rca, efficiënter en robuuster in alle aspecten vergleken met de EVO 4 componenten)
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 400.4 EVO6 - 4Ω
Power @ 4Ω: 2 x 66W RMS
Power @ 2Ω: 4 x 100W RMS
Bridge Power @ 4Ω: 2 x 200W
Bridge Power @ 2Ω: N/A -
Frequency Response (-3dB): 8Hz ~ 20kHz
-
Low Pass filter (12dB/octave): 80Hz
-
High Pass filter (12dB/octave): 80Hz
-
Operating Voltage: 9V ~ 16V
-
SNR: 94dB
-
Input Sensitivity (RCA): 0.2V ~ 2V
-
Current Draw (music): 20A
-
Current Draw (max.): 40.5A
-
Total Efficiency: 78%
-
Damping Factor (@100Hz nominal impedance): 200
-
Power Cable: 6mm² (9 AWG)
-
Speaker Cable: 2 x 1.5mm² (15 AWG)
-
Recommended Fuse (music): 25A
-
Recommended Battery (minimum): 40Ah
-
Width: 3.4" / 8.6 cm
-
Length: 4.2" / 10.7 cm
-
Height: 1.8" / 4.6 cm
-
Weight: 0,437 kg / 0.963 lb
