Beschrijving
SD EVO 5 wordt alleen aangeraden voor PA/Car speakers, PA/Car bullets, PA drivers en PA woofers.
Klik hier voor de SD 2400.4 EVOX2 (hogere kwaliteit mosfets, grotere power supply section, tiffany rca, efficiënter en robuuster in alle aspecten vergleken met de EVO 5 componenten)
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 2000.4 EVO 5 - 2Ω
Power @ 1Ω: 4 X 500W RMS
Power @ 2Ω: 4 X 330W RMS
Power @ 4Ω: 4 X 218W RMS
Bridge Power @ 2Ω: 2 X 1000W RMS
Bridge Power @ 4Ω: 2 X 660W RMS -
SD 2000.4 EVO 5 - 4Ω
Power @ 1Ω: N/A
Power @ 2Ω: 4 X 500W RMS
Power @ 4Ω: 4 X 330W RMS
Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 2 X 1000W RMS -
Operating Voltage: 9V – 16V
-
Current Draw (Music): 91A
-
Current Draw (Max): 182A
-
Recommended Fuse (Music): 100A
-
Total Efficiency: 87%
-
Damping Factor: 200
-
Frequency Response (-3dB): 10Hz – 22kHz
-
SNR: 90dB
-
Crossover
HPF: 80Hz
LPF: 80Hz -
Width: 5.4 in / 13,6 cm
-
Length: 9 in / 22,8 cm
-
Height: 2.2 in / 5,5 cm
-
Weight: 1,54 Kg
