- Maximum Power 12.6v @ 1 Ohm: 10000 WRMS
- Maximum Power 12.6v @ 2 Ohms: 8000 WRMS
- Nominal Impedance Efficiency: 76%
- Input Voltage: 9 - 15V
- Input Impedance: 100K Ohms
- THD Maximum Power: <1.5%
- Input Sensitivity: 300mV to 8V
- Signal to Noise Ratio: 80dBs
- Frequency Response: 22 to 1000Hz (-3dBs)
- HPF (Subsonic): 22 - 65Hz
- LPF (Crossover): 80 - 250Hz
- Variable Bass Boost: 30 - 80hz up to 12dB
- Recommended fuse: 600A
- Resting Current: ~2.5A
- Maximum Current (musical signal): 500A
- Maximum Current (sine signal): 1000A
- Power Cables (recommended min): 70mm / 0 AWG
- Weight (Kg): 9.2
- Height (mm): 73
- Width (mm): 256
- Depth (mm): 452
