Beschrijving
SD EVO 5 wordt alleen aangeraden voor PA/Car speakers, PA/Car bullets, PA drivers en PA woofers.
Klik hier voor de SD 3000.1 EVOX2 (hogere kwaliteit mosfets, grotere power supply section, tiffany rca, efficiënter en robuuster in alle aspecten vergleken met de EVO 5 componenten)
Klik hier voor de handleiding - Download hier de 1kHz test tone
-
SD 3000.1 EVO 5 - 1Ω
Power @ 1Ω: 1 X 3000W RMS
Power @ 2Ω: 1 X 1980W RMS
Power @ 4Ω: 1 X 1307W RMS -
SD 3000.1 EVO 5 - 2Ω
Power @ 1Ω: N/A
Power @ 2Ω: 1 X 3000W RMS
Power @ 4Ω: 1 X 1980W RMS -
Frequency Response (-3dB): 5Hz ~ 25kHz
-
Subsonic Filter: 5Hz ~ 80Hz
-
Low Pass Filter: 50Hz ~ 1kHz
-
Bass Boost: 0dB ~ 12dB @ 50Hz
-
Operating Voltage: 8V – 16V
-
SNR: 92dB
-
Input Sensitivity: 0.2V ~ 2V
-
Current Draw (Music):
1Ω: 149A
2Ω: 139A
4Ω: 140A -
Current Draw With Resistive Load:
1Ω: 298A
2Ω: 277A -
Total Efficiency:
1Ω: 80%
2Ω: 86% -
Damping Factor: >2000
-
Power Cable: 35mm² (2AWG)
-
Audio Output Cable:
1Ω: 2 x 6.0 mm² (9 AWG)
2Ω: 2 x 4.0 mm² (11 AWG) -
Recommended Fuse (Music): 150A
-
Recommended Battery: 150Ah
-
Width: 5.3 in / 13.6 cm
-
Length: 8.9 in / 22.8 cm
-
Height: 2.1 in / 5.48 cm
-
Weight: 1.75 Kg
