VIKING 15K - Amplifier Class | 1Ω - D |
Total Power 14,4 @ 1 Ohms |
1 x 19000 WRMS |
Total Power 12,6 @ 1 Ohm |
1 x 15000 WRMS |
Total Power 12,6 @ 2 Ohms |
1 x 9800 WRMS |
Input Voltage |
9 – 15V |
Input Impedance |
17 kOhms |
THD+Noise |
<1% |
Input Sensitivity |
160mV – 6V |
SNR |
82dB |
Frequency Response |
13Hz to 2kHz (-3dBs) |
Variable Subsonic Filter |
13Hz – 120Hz @ 12dB/octave Linkwitz-Riley |
Recommended Fuse |
Change the internal fuses with copper bars and use external fuses (2000A) |
Current at Rest |
3,5 A |
Average Current Draw (Music) |
630 A |
Weight (Lb) |
30,5 |
Height (in) |
2,5 |
Width (in) |
30,1 |
Depth (in) |
10,4 |
