SD 2000.2 EVO 5 - 2Ω
Power @ 1Ω: 2 X 1000W RMS
Power @ 2Ω: 2 X 660W RMS
Power @ 4Ω: 2 X 436W RMS
Bridge Power @ 2Ω: 1 X 2000W RMS
Bridge Power @ 4Ω: 1 X 1320W RMS -
SD 2000.2 EVO 5 - 4Ω
Power @ 1Ω: N/A
Power @ 2Ω: 2 X 1000W RMS
Power @ 4Ω: 2 X 660W RMS
Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 1 X 2000W RMS -
Frequency Response (-3dB): 10Hz ~ 20kHz
-
Low Pass Filter (LP -12dB/8): 80Hz
-
High Pass Filter (HP -12dB/8): 80Hz
-
Operating Voltage: 8V ~ 16V
-
SNR: 90dB
-
Input Sensitivity: 0.2 ~ 4V
-
Current Draw (Music):
2Ω: 89A
4Ω: 88A -
Current Draw With Resistive Load (1kHz @ 12.6V):
2Ω: 178A
4Ω: 176A -
Total Efficiency:
2Ω: 89%
4Ω: 90% -
Damping Factor (@100Hz Rated Impedance): 200
-
Minimum Audio Output Impedance:
2Ω: 1 ohm
4Ω: 2 ohms -
Minimum Bridge Impedance:
2Ω: 2 ohm
4Ω: 4 ohms -
Recommended Fuse (Music): 100A
-
Recommended Battery (Music): 100Ah
-
Width: 5.4 in / 13,6 cm
-
Length: 8.9 in / 22,7 cm
-
Height:
2.2 in / 5,5 cm
-
Weight: 3.39 lb / 1,54 Kg
