The USINA power supply was created with the main objective of powering the car's sound system without letting its batteries discharge, even with the sound playing for several hours.
It can also be used as a source and direct power supply (without the use of batteries), powering CD players, power modules.
Works with: Yinlong LTO, LiFePO4 and AGM
Input Voltage: Automatic Bivolt
AC 127Vac: 100 @ 140Vac
AC 220Vac: 170 @ 250Vac
Consumption 127Vac: 15A (maximum)
Consumption 220Vac: 8A (maximum)
Output Voltage: 12V @ 16Vdc (+-1%)
Output Current: 70A @ 12.5Vdc (+-5%)*
Output Power: 875 Watts (maximum)**
Efficiency: 85%
Input Power: 1075 Watts (maximum)**
Input Cable: 3x1.5mm² - 2P+T
Input Protection: 16A Circuit
Breaker Output Cable: 16mm²
Recommended Extension: 2.5mm² (max 30 meters)
Weight: 1.950 kg
Approximate Dimensions (LxWxH): 270mmX200mmX80mm***
*Current and power measured in resistive load
**Output power may vary according to mains voltage and usage conditions
***Measurements relating to the dimensions of the sources have a variation of approximately 2mm
