The Expert Electronics MX-PLAYER is a compact automotive audio mixer with built-in multimedia playback, designed to enhance car sound systems by combining a traditional mixer with modern media playback and flexible connectivity. It is ideal for car installers, DJs on the go, and anyone who wants professional-grade audio control with Bluetooth and USB media support.
Key Features & Capabilities
Versatile Audio Mixer with Playback
The MX-PLAYER functions as a 2-channel mixer supporting inputs for microphones, instruments, and line devices, and mixes them alongside music played from Bluetooth or USB.
Multiple Input & Output Connections
• Inputs: XLR (mic), 6.3 mm mono jack (P10), and RCA stereo connectors.
• Outputs: Main outputs via RCA and P10, plus an auxiliary line output with independent gain.
• Remote Output: REM OUT to control external equipment.
Built-In Player & Display
The integrated player includes:
• Bluetooth wireless audio streaming
• USB playback with folder navigation
• 16×2 LCD display enabling easy track and folder selection.
These features allow you to play music files without needing a separate media source.
4-Band Equalizer Per Channel
Each channel features a 4-band stereo equalizer (Low, Mid-Low, Mid-High, High) that allows ±18 dB adjustment per band so you can fine-tune your sound; the EQ is bypassed when set to center.
Monitoring & Control
• VU meter with multiple level indicators to visually monitor output signal levels.
• Peak/Clip indicators to help avoid distortion.
• Independent gain and level controls for precise mixing.
Automotive-Ready Power
Powered directly by 12 V DC, the unit eliminates the need for external inverters and reduces electrical noise, making it well-suited for car installations.
Technical Specifications
Inputs
• Type: XLR / 6.3 mm Jack (P10) / RCA Stereo
• Frequency Response: 10 Hz–30 kHz @ –1 dB
• Mic Gain: up to +20 dB
• Max Input Level: +12 dBu @ +10 dB gain 5.6Vrms
• Impedance: 18 kΩ
• Signal-to-Noise Ratio: 110 dB
• THD+N: >0.1 %
Equalizer
• Low: 60 Hz ±18 dB
• Mid-Low: 250 Hz ±18 dB
• Mid-High: 1.7 kHz ±18 dB
• High: 11 kHz ±18 dB
Outputs
• Main & Aux Outputs: P10 and RCA connectors
• Max Output Level: +17 dBu / 5.6Vrms
• Impedance: 470 Ω
Power
• Operating Voltage: 10–14.4 V DC
• Designed for 12 V automotive systems
Dimensions & Weight
• Approx. 240 × 152 × 45 mm
• Weight around 0.68 kg
